Description:

Combining commercial-grade features and powerful performance in a compact design, the Model 125V riding lawn mower with zero-turn maneuverability is ideal for tight quarters mowing and is a great way to step up to Grasshopper comfort, quality and durability.

MidMount™ Mower Decks

Superior Strength and Durability

Grasshopper MidMount™ mower decks offer superior strength and durability with minimal service. Coupled with a deep deck design that enhances airflow, these qualities provide a superior cut while reducing worries about downtime and repairs.

Versatile MidMount™ mower decks let you change the way you mow without changing decks, facilitating easy conversion from standard side discharge to optional Down Discharge™ mulching or PowerVac™ collection with the same deck. In addition, our 4X Dedicated Rear Discharge™ deck provides a manicured cut while keeping the clippings on the turf and away from roadways and sidewalks.

Features:

• Heavy-duty Deck
• Vigilant Operator Presence System™
• Shock Impact Reduction System™(SIRS™)
• Kohler Confidant Engine
• QuikAjust® Drop Pin Height Adjustment
• Warranty
• Design-Matched Transmission
• Ultimate Operator Station™
• Reduced Maintenance
• Rugged Construction

Specifications:

• Engine Information
• Type: Kohler Confidant, V-Twin
• Horsepower: 45.6 cu. in. (747 cc)
• Lubrication System: Pressure Lube/Filter
• Crankshaft: Vertical
• Cooling System: Air
• Fuel: Gasoline - unleaded
• Fuel Capacity: 6.5 U.S. Gal. (24.6 l)
• Air Cleaner: Heavy-duty cyclonic air filter with QUAD-CLEAN™ multi-stage air filtration
• Muffler: Ultra quiet, single, industrial type
• DURAMAX® Deck
• Deck Size: 52" Deck
• Cutting Height Range: 1.0 to 4.5 in. (2.5 to 11.4 cm)
• Construction: Robotic-welded, double-layered 10-gauge plus 10-gauge formed-steel spindle plane (0.269 in / 6.83 mm thick) with 7-gauge skirts. Anvil-edge design with 0.5 in. (12.7 mm) reinforcement on front edge of deck.
• Blades:
• 3) 18 in. (45.7 cm)
• Spindle Assemblies: Sentry™ Spindle System with 2.5 cm (approx. 1 in.) O.D. shaft. Double bearings, non-greasable. Shield housing and lower bearings to protect from fiber wrap and dirt ingestion.
• Spindle Housings: 8 in. (20.3 cm)-diameter machined aluminum housing with 6-bolt pattern
• Blade Drive: Belt drive with single Kevlar V-belt and idler arm tensioning.
• Starter & Electrical System
• Battery: 12 Volt, maintenance-free
• Starter: Solenoid shift
• Ignition: Breakerless
• Interlock System: Prevents engine start when PTO clutch is engaged or steering levers are in drive position.
• Ultimate Operator Station
• Seat: Iso-mounted Premium Comfort Seat. Features include high-back, deep-cushioned, foam-padded Cordura®-covered, padded foldable arm rests, padded backrest with lumbar support, coil-spring suspension, and embroidered Grasshopper logo.
• Suspension: Iso-mounted footrest with Shock Impact Reduction System™ (SIRS™).
• Console-mounted Instruments: Digital hour meter, parking brake indicator light, ignition switch, choke, and push/pull PTO switch.
• Work Lights: Optional LED
• Transmission & Steering
• Type: Design-matched hydrostatic system with in-line cooling fans, fully hydraulic, integrated Parker HT Series transmission with variable displacement piston-type pumps and high-torque wheel motors.
• Speed: 0 - 8.0 mph (0 - 12.9 kph) forward, 0 - 6.0 mph (0 - 9.7 kph) reverse
• Turning Radius: True zero-degree, turns within its own length with counter-rotating, independently powered drive wheels.
• Steering: Adjustable HydraSmooth™ dual levers that automatically return to neutral from either forward or reverse position.
• Brakes: Dynamic braking through hydrostatic transmission, Parking brake: Compression
• Tire Sizes
• Drive Wheels (Standard, 4-ply rated): 20x10x10 turf, 4-ply rated
• Front Wheels: 13x6.50x6; pneumatic with greasable, double-sealed bearings
• Deck Tires (4-ply rated): NA
• Dimensions
• Height (Seat Back): 47.0 in. (119.4 cm)
• Height (Seat Cushion): 29.0 in. (73.7 cm)
• Height (ROPS): 59.0 in. (149.9 cm)
• Length (midmount w/ DuraMax® Deck - Mowing Position): 75.0 in. (190.5 cm)
• Deck Width (Side Discharge): 65.5 in. (166.5 cm)
• Deck Width (Mulch): 53.5 in. (135.9 cm)
• Weight (Uncrated)
• 52" Deck: 830 lbs. (376.5 kg)
