DESCRIPTION

72" Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI - air-cooled, electronic fuel injection

FEATURES

• The envy of the neighborhood - 52", 61" or 72" Cutting Width: The envy of the industry, Velocity Plus™ decks deliver an amazing quality-of-cut and a wide, even discharge. This deck is equipped with Scag's ultra-tough cast-iron spindles featuring tapered roller bearings and a top-mounted grease fitting with a relief valve to prevent over-greasing.
• Heavy-Duty, Double-Tube Steel Main Frame - Solid Design for Years of Dependable Service: The Turf Tiger™ is ultra-strong and built for long life. It has a wide mower stance and extra-low center of gravity for ultimate stability and a replaceable front caster-wheel weldment.
• Powerful and Efficient Engine Options - Huge Power, Up To 40 HP: Choose from a Kawasaki®, or Briggs Vanguard™ engine; air-cooled or liquid-cooled; electronic fuel injection (EFI) or digital fuel injection (DFI) options. Diesel (Kubota) and propane (Kohler) options are also available.
• Huge 26" Drive Tires - Roll Fast and Smooth: Large, 6-ply drive tires deliver superior traction, a smooth ride and allow for easy curb-climbing capability.
• Tiger Eye Advanced Monitoring System - Keep a Real-Time "Eye" on Important System Functions: Depending on the mower model and engine selection, the Tiger Eye™ Advanced Monitoring System monitors a wide variety of systems in real-time, giving you valuable information in just a glance, right from the operator's seat.
• Command-Comfort Operator Station - The Turf Tiger Command-Comfort Operator Station Is Built Around YOU.: Components include a torsion-spring suspension seat mounted on a 4-iso-mount system, Quick-Fit™ adjustable steering levers, and an adjustable deck-lift pedal.
• Auxiliary Hydraulic Oil Cooler - Efficient Operation and Added Reliability: Standard-equipment oil cooler extends system life by keeping the hydraulic oil cooler. Cooler location utilizes the engine airflow to draw cool air through the cooling fins.
• Industrial-Grade Hydraulic System - Speeds Up To 12 MPH: Dual Hydro-Gear pumps (16 cc) and Parker wheel motors (18 ci) deliver dependable power. Pump shock valves ensure reliability and long life. Cooling fans help maintain safe operating temperatures.
• Driveshaft-Driven Cutter Decks - Another Reason the Turf Tiger is King of the Jungle.: A driveshaft connects the engine to the deck, eliminating the long belt drive and increasing cutting-height range.

SPECIFICATIONS

• Description: 72" Velocity Plus™ Cutter Deck, 38 HP Kohler® Command PRO® EFI - air-cooled, electronic fuel injection
• Total Fuel Capacity: 12 gallons (Gas/Diesel); 33.5 lb (LP)
• Drive Tires: 26" x 12"-12" (61" and 72"); 26" x 9.5"-12" (52")
• Caster Tires: 13" x 6.5"-6"
• Seat: 4-point iso-mounted torsion-spring suspension seat
• Drive System Type: Dual Pump and Motor
• Pumps: Hydro-Gear: 16 cc
• Motors: Parker: 18 ci
• Forward Ground Speed: 12 mph (Gas/LP); 10 mph (Diesel)
• Reverse Ground Speed: 6 mph
• Parking Brake: Adjustable foot-operated pedal. AUSCO disc brakes.
• Cutting Widths: 52", 61" and 72"
• Type: Velocity Plus™
• Cutting Height: 1.5" to 6" in .25" increments
• Deck Lift: Adjustable foot-operated pedal
• Construction: Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2" of steel. Reinforcement plates at cutter deck spindles.
• Spindles: Cast-iron housing with tapered roller bearings.
• Blade Engagement: Ogura GT3.5 (300 ft lb); Ogura GT5 (350 ft lb) (Briggs Models); Adjustable air-gap for extended life.

DIMENSIONS

• Length: 89.5" / 92"
• Width (chute down): 83"
• Width (chute in transport position): 73.75"
• Height (ROPS down): 46.5"
• Height (ROPS up): 68"
• Weight: 1,556 lb / 1,739 lb

ACCESSORIES

• Clam-Shell Grass Catcher
• 3-Bag Grass Catcher
• Hurricane Plus™ Mulch System
• Mulch Plate
• OCDC - Operator-Controlled Discharge Chute
• Tiger Stripe Kit
• Light Kit
• Trailer Hitch
• Chrome Wheel Covers
• Air Filter Monitor
• Blade Buddy
• Turf Tiger Bumper
